The product view is a rendering built from the manufacturer solid for this part number, not stock photography. No dimensioned drawing of P2626 is published on this site.
90° angle fitting · 1-5/8 in. series
P2626 — 2-Hole 90° Angle Fitting, 2-1/8 in. Square
A single steel plate bent once through 90° with equal 2-1/8 in. legs and one 9/16 in. bolt hole in each. Equal legs are what separate it from every other two-hole angle on the same catalog page.
By Alex · Last reviewed 2026-09-25 · Spec looks wrong? Tell us.
- Size
- 2-1/8 × 2-1/8 in. (54.0 × 54.0 mm)
- Holes
- 2 × 9/16 in. (14.3 mm), one per leg — for 1/2 in. bolts
- Steel
- About 0.23 in. (5.8 mm) base steel before coating; a hot-dip galvanized part measures thicker; catalog reference part 1/4 in. (6.4 mm)
- Fits
- 1-5/8 in. series strut channel
- Catalog ref.
- Unistrut® GEC no. 17, pp. 85, 94
Dimensions above are the catalog specification for the reference part; the steel line is our supply. Steel grade is confirmed at quotation.
P2626-EG — electro-galvanized, zinc plating to ASTM B633 Type III SC1. Smooth bright silver. Indoor and dry service. P2626-HG — hot-dip galvanized to ASTM A123 or A153. Visible spangle, heavier edge build-up. Outdoor, wet and coastal service. P2626-PL — plain, uncoated steel. For painting or powder coating after assembly, or dry enclosed runs. Stainless — the catalog offers stainless, aluminum and fiberglass on some part numbers but publishes no standard suffix for them and says to consult the factory. Quote as made-to-order. Powder-coated — powder coating to a customer-specified RAL color. Not a catalog finish, so it carries no catalog code — the color, which parts take it and the film build are confirmed at quotation. We publish no film thickness and no salt-spray figure, because we have not measured one.
Finish list: Unistrut® General Engineering Catalog no. 17, p. 85 — finishes note. Powder coating is our option, not a catalog finish. The catalog also lists GR against this series — not quoted, see Finishes.
Pack: Packed per order. One cap screw and one channel nut per leg, ordered separately.
Catalog figures for the reference part, with where each one comes from. Our supply thickness is in Supply summary.
| Dimension | Catalog value (reference part) | Source |
|---|---|---|
| Leg lengths | 2-1/8 in. (54.0 mm), both legs | Unistrut® General Engineering Catalog no. 17, p. 94 — printed on the part drawing |
| Hole count | 2, one per leg | Unistrut® General Engineering Catalog no. 17, p. 94 — printed on the part drawing |
| Width | 1-5/8 in. (41.3 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Hole diameter | 9/16 in. (14.3 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Hole center from the free end | 13/16 in. (20.6 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Material thickness | 1/4 in. (6.4 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Steel | ASTM A575 / A576 / A635 / A36 | Unistrut® General Engineering Catalog no. 17, p. 85 — fittings material note — also meets the physical requirements of A1011 SS GR 33 |
| Bend radius | not published | Not dimensioned on p. 94. |
| Hole center to the bend | not published | Not dimensioned on p. 94, and not derived here from leg length minus end distance. |
The leg length is printed on the P2626 drawing. Width, hole diameter, end distance and thickness come from the p. 94 header note, which the P2626 drawing does not override.
The rest of the two-hole 90 degree group
P2626 is the only equal-legged member of the group and the heaviest of the short ones. If the description you were given says only “2 in. angle”, P2626 and P1026 are both candidates and they are not the same part.
| Part | Legs | Holes |
|---|---|---|
| P1723 | 1-5/8 x 1-7/8 in. (41.3 x 47.6) | 2 (1 tapped 5/16 in.-18) |
| P1068 | 1-5/8 x 2-1/4 in. (41.3 x 57.2) | 2 |
| P1026 | 2 x 1-7/8 in. (50.8 x 47.6) | 2 |
| P2626 | 2-1/8 x 2-1/8 in. (54.0 x 54.0) | 2 |
| P1281 | 3 x 1-7/8 in. (76.2 x 47.6) | 2 |
| P1282 | 3-1/2 x 1-7/8 in. (88.9 x 47.6) | 2 |
| P1283 | 4 x 1-7/8 in. (101.6 x 47.6) | 2 |
Source: Unistrut® General Engineering Catalog no. 17, p. 94 — printed on the part drawing
What bolts through it, and where the published data stops.
Hardware. One 1/2 x 15/16 in. hex head cap screw and one 1/2 in. channel nut per leg — P1010, P4010 or P5510 by channel series. Not supplied with the fitting.
Twist. One bolt per leg, so the joint can rotate about either bolt if the corner is loaded sideways. Equal legs make this fitting a tidy choice for a corner that is doubled — two fittings back to back on opposite faces of the channel present the same geometry either way up, which a handed part does not.
Load rating. The catalog publishes no load figure for P2626, so neither do we. Where the catalog gives design load data for a fitting it states the data is based on the ultimate strength of the connection with a safety factor of 2.5; no such figure appears on p. 94 for this part.
What the published cross-reference tables print opposite P2626.
| Brand | Published cross-reference part number |
|---|---|
| B-Line | B231 [S1][S3][S4] |
| Superstrut | AB299 [S1][S3] |
| Power-Strut | PS 806 [S1][S3] |
| Haydon | A-304 [S3] |
A published cross-reference number is one thing only: a number a cited document prints opposite this one, as a candidate substitute in the same catalog slot. It carries no load rating, steel grade, coating thickness or third-party listing — each manufacturer publishes those separately and they do not travel with a part number. Source documents, access dates and what to measure before you fit a substitute: Unistrut P2626 cross reference.
Source: our cross-reference dataset, built 2026-09-09 from the documents listed below.
What a P2626 actually is
One piece of steel plate, one 90° bend, one bolt hole in each leg, and both legs the same length at 2-1/8 in. It is the square corner of the 1-5/8 in. fitting line. The legs are 1-5/8 in. wide, matching the channel face, so the fitting sits inside the footprint of the run.
Equal legs are not a cosmetic property. A symmetrical angle can be fitted either way round and still present the same hole position to both channels, which removes a whole class of site error on a job with a lot of corners. It also means one part number covers both hands of a detail that would otherwise need two.
Choosing between P2626 and the angles next to it
P2626 is 2-1/8 in. square. P1026 is 2 x 1-7/8 in., P1068 is 1-5/8 x 2-1/4 in., and P1281 through P1283 run 3, 3-1/2 and 4 in. on the long leg against a fixed 1-7/8 in. short one. The practical gap P2626 fills is the one where 2 in. does not quite reach on both sides: an eighth of an inch more on the short leg is often exactly what clears a lip, a weld bead or a bolt head.
A longer leg buys reach, not strength. The bolt lands in the same channel slot whatever the leg length, and the connection is still one bolt per leg. Order the shortest leg that reaches, and where the corner must hold its angle under a sideways push, double it or brace it rather than going up a size.
Checking an incoming shipment
Four checks, and on this part number the first two are the whole job.
1. Measure both legs: 2-1/8 in. (54.0 mm) each. Measure over the corner, from the free end of one leg to the outside face of the other. Equality is the identifying feature of P2626 — if the two legs differ, you have been sent a different part number regardless of what the carton says.
2. Count the holes: two, one in each leg. Every 90° angle on catalog p. 94 has one hole per leg, so a four-hole part is not a substitute from that page at all.
3. Measure hole center to the free end: 13/16 in. (20.6 mm). This decides whether the hole lines up with a channel nut in the slot. It is the series pattern, and a part that misses it will not sit flat on the channel face.
4. Caliper the plate thickness away from the bend and compare it with the base-steel thickness on your quotation. A free edge, not a formed corner. Our standard plate is about 0.23 in. (5.8 mm) base steel before coating; a hot-dip galvanized part measures thicker. The catalog reference part is 1/4 in. (6.4 mm). Compare the base-steel thickness on your quotation; measure a galvanized part knowing the coating adds to it. A 3/16 in. (4.8 mm) plate looks the same in a bin — that is the one to reject.
Related parts
- P1026 — 2 x 1-7/8 in. legs — the standard bracket, and the one part on this site with a dimensioned drawing.
- P1068 — 1-5/8 x 2-1/4 in., the unequal-legged alternative at the same size.
- P1000 — The channel this fitting is drawn against.
- P1010 — One nut per leg, with a 1/2 x 15/16 in. cap screw.
- Finish options — PL, EG, HDG and stainless, and which of them we can supply.
What we can quote against this part number
We do not manufacture these parts and we are not Unistrut. We source them. The item we can quote against Unistrut P2626 is 90 degree angle fitting, 2-1/8 x 2-1/8 in., 2 holes — a candidate substitute made to order by a contract manufacturer, offered for inquiry, not an original-manufacturer part.
| Dimension | Value | Source |
|---|---|---|
| Leg lengths | 2-1/8 in. (54.0 mm), both legs | Unistrut® General Engineering Catalog no. 17, p. 94 — printed on the part drawing |
| Width | 1-5/8 in. (41.3 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Holes | 2, one per leg, 9/16 in. (14.3 mm) | Unistrut® General Engineering Catalog no. 17, p. 94 — printed on the part drawing and Unistrut® General Engineering Catalog no. 17, p. 94 — standard-dimensions note in the page header |
| Thickness | About 0.23 in. (5.8 mm) base steel before coating; a hot-dip galvanized part measures thicker. Steel grade confirmed at quotation. | Our supply specification — not a catalog figure |
These are the published Unistrut catalog dimensions we build to, each with the page it is printed on. The thickness row is the exception: it states what we supply, not a catalog figure. They are geometry only. No load, torque or listing figure is claimed for our part: none has been tested on it, and a figure published for a Unistrut part is evidence about that part, not about ours.
Supply summary
What is known about supplying this part number, and nothing that is not. Anything missing from this list is missing because we do not have it yet, not because it was left out.
- Reference part
- Unistrut® P2626, as published in the Unistrut® General Engineering Catalog no. 17
- What we quote against it
- 90 degree angle fitting, 2-1/8 x 2-1/8 in., 2 holes — a candidate substitute made to order by a contract manufacturer, offered for inquiry, not an original-manufacturer part.
- Plate thickness
- About 0.23 in. (5.8 mm) base steel before coating; a hot-dip galvanized part measures thicker. Steel grade confirmed at quotation.
- Finishes available
- Plain, EG, HDG and stainless, plus powder coating on request.
- Documents we can provide
- A dimension drawing traced from the catalog page cited above. A material certificate on request — availability and cost are confirmed at quotation, per mill.
- Lead time
- Production lead time: 5–7 business days, ex-factory. Counted from order confirmation and receipt of deposit (or drawing approval for custom parts, whichever is later). This does not include transit.
- How to confirm fit
- Measure the incoming parts against "Checking an incoming shipment" on this page, before the carton goes into stock.
Get this part number quoted
Answer the seven lines below and we come back with our part number, finish options, lead time, packing quantity and what documentation we can and cannot supply. There is no list price — it is quoted per mill, finish and volume. The form takes about a minute and already knows this part number. We reply within one business day (Asia/Shanghai, UTC+8).
- Unistrut part number — P2626
- The brand and part number you are replacing
- Finish
- Quantity
- Destination — country, and state or ZIP if US
- Application — general support, electrical, mechanical, seismic, or a listed assembly
- Whether you need submittal documentation
No minimum order · 5–7 business days ex-factory · Reply within one business day (Asia/Shanghai, UTC+8) · Finishes: plain, EG, HDG, stainless
